Limited Supply - Contact us prior to purchase • Cost-effective solution - $319.00(incl. GST) • 2-axis g-force measurement - positive and negativs g's • Compact at 52 x 32 x 12.5 mm and less than 45 grams • Two mounting options • Flexible connector options • Various bandwidth options - from 1 Hz to 500 Hz • Machined anodised aluminium housing • Download the PDF! • Buy Now using PayPal!

Parameter	Minimum	Typical	Maximum	Units
Measurement Range	-	18	-	g
Zero g Voltage	1.5	1.65	1.8	V
Sensor Output Voltage	0	-	3.3	V
Sensitivity	56	63	70	mV/g
Stability	-	+/-0.01	-	% per degree C
Temperature Range	-20	-	70	degrees C
Nonlinearity	-	+/-0.2	-	%
Inter-Axis Alignment Errors	-	+/-0.1	-	%
Cross-Axis Sensitivity	-	+/-2	-	%
Supply Voltage	6	-	12	V Sensor Supply
Supply Current	-	1	-	mA
